BJ1251

Color: Black (Other colors can be customized)

Standard size

Width: 19；25 millimeters

Length: 20 meters

Inner diameter of the paper tube: 38 millimeters

(Other sizes can be customized)

Performance	Units	Typical values	Test method
Total thickness	mm	0.18±0.03	ASTM D1000
Tensile strength	N/cm	＞65	ASTM D1000
Elongation	%	＞10	ASTM D1000
Peel force (for steel plates)	N/cm	＞2.0	ASTM D1000
Peel force (for the substrate)	N/cm	＞2.0	ASTM D1000
Noise reduction	dB(A)	A:0~2	GMW16740/LV312
Wear-resistant	Cycle	B	GWT A D14-10
Flame retardancy	-	B	GMW16740/LV312
Unwinding force	N/cm	2~6	VW60360
Operating temperature	℃	-40/+125	LV312

Note: The above data are typical figures based on test results and are not used as product specifications. For detailed information, please contact Lantor Technology.

Specially designed for protective winding of automotive wiring harnesses, electronic wiring harnesses, etc., it is suitable for confined areas and limited installation Spaces.

It can be stored for 12 months in the original packaging box at 23℃×65%RH, away from direct sunlight.
