Product Center
Good quality and low price, widely praised
Automotive Wiring Harness Tape General tape Plastic products
LTD150
PET film, acrylic adhesive, PCK, 90℃

Made of high-strength acrylic adhesive, high-performance PET film and polyester-coated kraft paper (PCK), it features excellent adhesion, weather resistance and good holding power.

Color: Brown (customizable color)

Standard size

Width: 25 "40; 50 millimeters

Length: 15 20 meters

Inner diameter of the paper tube: 76 millimeters

(Other sizes can be customized)

Technical Indicators:

Project

Typical Value

Units

Test Method

Thickness

0.15±0.05

mm

ASTMD1000

180° Peel Strength

13.7

N/10

ASTMD3330

Breakdown Voltage

6900

min/1kg/25㎜)



Applicable Temperature

80



Note: The above data are typical figures based on test results and are not used as product specifications. For detailed information, please contact Lantor Technology

It has good bonding strength for most plastic surfaces, including polypropylene and powder coating. Even for the oil-stained surfaces of mechanical parts, acrylic adhesives have excellent bonding properties.

Disclaimer:This product is an industrial product that has not been designed or tested and is not suitable for certain automotive applications, such as automotive electric powertrain batteries or high-voltage applications. These applications may require the product to be manufactured on IATF-certified equipment, and all performance indicators must reach a Ppk value of 1.33, undergoing the automotive Production Parts approval process (PPAP). Or fully comply with the requirements of automotive design or quality systems (such as IATF 16949 or VDA6.3). If the customer chooses to use this product in these applications, the customer shall bear all responsibilities and risks.









The storage temperature range is 20 to 30℃, the humidity is below 65%, and direct sunlight should be avoided. It can be stored for 2 years in the original packaging box.
